UN U-Cup Seal

UN-Cup Seal is a product developed, designed and produced by Ruichen Seal considering the sealing needs of mechanical equipment in multiple fields. It has a symmetrical structure and is widely used in piston and piston rod sealing conditions of automobiles, agricultural machinery, cranes, mining equipment and forestry machinery. It has wear resistance, easy installation and adaptability to working conditions.

Send Inquiry

Product Description

UN-Cup Seal is a symmetrical seal designed for use on pistons or piston rods. It is used in mobile machinery, light industrial machinery, agricultural machinery, cranes, automobiles, forestry machinery, mining machinery, etc.

Working Conditions

Pressure Mpa	Temperature ℃	Speed m/s	Media
≤40	-35~+100	≤0.5	Hydraulic oil, emulsion, etc.

Materials

Standard material: Polyurethane (PU). Nitrile rubber (R01) and fluororubber (R02) are also available (please consult our company).

Ordering Example: Universal seal for shaft and bore: UN50x65x10PU(dxDxH) + material code
